GIGABYTE P650B GP-P650B 650 W Intel Form Factor ATX 12V v2.31 80 PLUS BRONZE Certified Non-Modular Active PFC (>0.9 typical) PFC Power Supply

₨23,000.00

Dear Visitor, All previous Prices & Quotes are Null n Void due to continuous rise of US Dollar.
Description

GIGABYTE P650B GP-P650B 650 W Intel Form Factor ATX 12V v2.31 80 PLUS BRONZE Certified Non-Modular Active PFC (>0.9 typical) PFC Power Supply Price in Pakistan

General
Brand GIGABYTE
Series P650B
Model GP-P650B
Details
Type Intel Form Factor ATX 12V v2.31
Maximum Power  650 W
Fans  1 x 120mm Hydraulic Bearing Fan
PFC  Active PFC (>0.9 typical)
Main Connector  20+4Pin
+12V Rails  Single
PCI-Express Connector  4 x 6+2-Pin
SATA Power Connector  6
Modular  Non-Modular
Efficiency  Up to 85% at typical load
Energy-Efficient 80 PLUS BRONZE Certified
Over Voltage Protection  Yes
Protection OPP / UVP / OVP / SCP / OCP
Input Voltage 100 – 240 V
Input Frequency Range 50/60 Hz
Input Current 9A – 4A
Output +3.3V@18A, +5V@15A, +12V@54A, [email protected], [email protected]
MTBF  >100,000 Hours
Approvals CE/ CCC/ BSMI/ KCC/ EAC/ UL/ TUV/ RCM/ FCC/ PSE
Max PSU Length 140 mm
Connectors 1 x ATX/MB 20+4 Pin
1 x CPU/EPS 4+4 Pin
4 x PCI-e 6+2 Pin
6 x SATA
3 x Peripheral
1 x Floppy
Features
Features 80 PLUS bronze certified: up to 89% efficiency

100% Japanese Capacitors

120mm Hydraulic Bearing (HYB) Fan

Single +12V rail

Meet ErP LOT6 2013 (< 0.5W at standby mode)

OPP/UVP/OVP/SCP/OCP protection
Dimension & Weight
Dimensions 3.39″ x 5.51″ x 5.91″
