GIGABYTE GP-UD750GM 750 W ATX 12V v2.31 80 PLUS GOLD Certified Full Modular Active PFC Power Supply Price in Pakistan
| Brand | GIGABYTE |
|---|---|
| Model | GP-UD750GM |
| Type | ATX 12V v2.31 |
|---|---|
| Maximum Power | 750 W |
| Fans | 120mm Hydraulic Bearing (HYB) fan |
| PFCÂ | Active |
| Main Connector | 20+4Pin |
| +12V Rails | Single |
| PCI-Express Connector | 4 x 6+2-Pin |
| SATA Power Connector | 8 |
| Modular | Full Modular |
| Power Good Signal | 100-150ms |
| Hold-up Time | >16ms |
| Efficiency | 90% at typical load |
| Energy-Efficient | 80 PLUS GOLD Certified |
| Protection | OVP/OPP/SCP/UVP/OCP/OTP |
| Input Voltage | 100 – 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 12-6A |
| Output | [email protected], [email protected], [email protected], [email protected], [email protected] |
| MTBFÂ | >100,000 Hours |
| Approvals | BSMI/CE/CCC/FCC/TUV/RCM/CB/EAC/KCC/UL/PSE |
| Max PSU Length | 140 mm |
| Connectors | 1 x 24 pin (20+4) ATX 2 x 8 pin (4+4) EPS (CPU) 4 x 8 pin (6+2) PCIe 8 x SATA 3 x 4 pin Peripheral 1 x Floppy |
| Cable Spec | 20+4Pin MB: One cable (610mm) 4+4Pin CPU: Two cables (600mm) 2 x PCI-E 6+2Pin: Two cables (600+150mm) 4 x SATA: Two cables (600+150+150+150mm) 3 x 4Pin Peripheral + 4Pin floppy: One cable (500+120+120+150mm) |
| Features | Ultra Durable – Main Japanese capacitors – Enhanced thermal solution – 120mm smart hydraulic bearing (HYB) fan – OVP/OPP/SCP/UVP/OCP/OTP protection 80 PLUS Gold certified Fully modular design Powerful single +12V rail Compact design |
|---|
| Dimensions | 3.39″ x 5.91″ x 5.51″ |
|---|
